RCD510
1. Aerial Connector
DAB aerial input connection, optional
or SDARS aerial input connection for
vehicles for USA and Canada
2.
Multi-pin connector 1, 8-pin, for loudspeaker
outputs
1 – Rear right loudspeaker,
positive
2 – Front right loudspeaker, positive
3 – Front left loudspeaker, positive
4 – Rear left loudspeaker, positive
5 – Rear right loudspeaker, negative
6 – Front right loudspeaker, negative
7 – Front left loudspeaker, negative
8 – Rear left loudspeaker, negative
3. Multi-pin connector 2,
8-pin, for voltage supply lines and CAN bus
9 – CAN bus, high
10 – CAN bus, low
11 – Display voltage supply,
positive
12 – Voltage supply,
negative, terminal 31
13 – Display HV CAN bus low
14 – Display HV CAN bus high
15 – Voltage supply,
positive, terminal 30
16 – Anti-theft coding
control signal, SAFE, positive
4. Multi-pin
connector 3, 12-pin, for telephone and
microphone signals
1 – Microphone input,
negative
2 – AUX output, audio, right
3 – AUX output, common
signal earth
4 – Microphone output,
negative
5 – Telephone audio input
signal left, negative
6 – Telephone audio input
signal right, negative
7 – Microphone input,
positive
8 – AUX output, audio, left
9 – Microphone output,
positive
10 – Telephone mute (mute
switch for radio)
11 – Telephone audio input
signal left, positive
12 – Telephone audio input
signal right, positive
5. Multi-pin connector 4, 12-pin,
for CD changer control and CD audio input
signals
1 – AUX signal input, left
2 – AUX signal earth
3 – CD changer, audio signal earth
4 – CD changer, voltage supply, positive,
terminal 30, contact continuous load greater
than 1 A, temporary peak load 5 A
5 – Not assigned
6 – CD changer, DATA OUT
7 – AUX signal input, right
8 – CD changer, left audio channel, CD/L
9 – CD changer, right audio channel, CD/R
10 – CD changer, control line, switched
positive
11 – CD changer, DATA IN
12 – CD changer, CLOCK (internal check protocol
for data flow monitoring)
6. Multi-pin connector 5,
audio and video, 26-pin
(this will only be fitted to
models fitted to vehicles with RVC factory
fitted or ordered through spare parts with the
RVC input option)
1 – Reserved for Debug RX
protocol
2 – Reserved for Debug TX protocol
3 – Not assigned
4 – Video signal input, RGBS,
negative (ground)
5 – Video signal output LF, Right (Audio use 17
for ground)
6 – Ground Sync input
(Internal universal preparation for
mobile telephone, mobile telephone detection)
7 – Video signal output, vertical and
horizontal synchronisation(Internal universal
preparation for mobile telephone, cradle and
button evaluation)
8 – Video signal ouput, green
(Internal universal preparation for mobile
telephone, cradle, aerial diagnosis)
9 – Video signal input, RGBS, negative (ground)
10 – Video signal input LF, right (Audio use
24 for ground)
11 – Video signal input, screening earth
12 – Video signal input, vertical and
horizontal synchronisation
13 – Video signal input, green
14 – Not assigned
15 – Not assigned
16 – Not assigned
17 – Video signal output, LF, negative (ground)
18 – Video signal output LF, Left (Audio use
17 for ground)
19 – Video signal output, RGBS, negative
(ground)
(Internal universal preparation for mobile
telephone, cradle, negative)
20 – Video signal output, Blue
(Internal universal preparation for mobile
telephone, switched terminal 30)
21 – Video signal output, Red
22 – Video signal input, LF, negative
23 – Video signal input, LF, left (Audio use 24
for ground)
24 – Video signal input, RGBS, negative
(ground)
25 – Video signal input, blue
26 – Video signal input, red
7. Aerial Connector
AM/FM aerial input connection
8. Aerial Connector
FM 2 aerial input connection
|
|
